Revolutionary Technology
Our patented panel construction combines recycled plastics with advanced materials to create the most resilient, sustainable building system available.
Panel Construction
8 precision-engineered components working in harmony
Cement Fibre Board (fire-resistant, durable)
Thermal Sheets (insulation)
I-Beam Grid (thermo-fused single-use plastic)
Anchor Bolts (6-inch, concrete foundation connection)
Runners with Thermal Sheets (rubber sealing)
Stainless Steel Fasteners (304/316 grade)
Metal Rafters (roof support)
Load Distribution Unit
Technical Specifications
Performance metrics that exceed industry standards
Panel Layer Construction
Panel Size
8' x 4' x 4"
Thermal Conductivity
0.04 W/m.K
37.5x better than concrete
Sound Absorption
>38dBA
Water Absorption
0.40%
Compression Load
10.9 MPa
Fire Rating
60-240 minutes
Wind Load Resistance
1000 kg/m²
Acoustical Rating
>33 R'W
Testing & Validation
All Circato panels undergo rigorous testing and validation by internationally recognized certification bodies including SGS and other leading laboratories.
Fire Testing
Fire resistance tested from 60 to 240 minutes according to international standards
Wind Load
Tested to withstand extreme wind conditions up to 1000 kg/m²
Acoustical Performance
Sound absorption and transmission loss testing exceeding building codes
Solar Heat Simulation
Thermal performance validated under extreme temperature conditions
